Organic Fertilizer Semi Wet Material Crusher

【Capacity】1-12T/H
【Power】7.5-37kw
【Introduction】This organic fertilizer semi-wet material crusher is an ideal machine for fertilizer production and processing units, which can shorten the process of organic fertilizer and compost production, reduce the investment of equipment, and save operation costs.

Applications and Features

The water content of organic fertilizer for biological fermentation is allowed to reach 25-50%. The partied size can reach the requirement of granulation, it also can be adjusted according to the needs of users to a certain extent. The crusher can grind the glass, ceramic, brick, stone, and other hard materials in the organic fertilizer of municipal solid waste, in this way the effect of application is achieved. This machine is an ideal machine for fertilizer production and processing units, which can shorten the process of organic fertilizer and compost production, reduce the investment of equipment, and save operation costs.

Working Principle and Characteristics

  • 01. Semi-wet material crusher adopts a two-stage rotor up and down two stages of crushing, the material is through the upper rotor crusher into fine particles, and then transported to the lower rotor to continue to crush into fine powder to achieve the best effect of powder, hammer powder, and finally discharge directly from the discharge port.
  • 02. Semi-wet material crusher does not design screen bottom, more than 100 kinds of materials can be crushed, and will not be blocked. Even the material just pulled out of the water can be crushed, and will not be blocked by the wet material crushing, causing the motor to burn out and affecting production.
  • 03. Semi-wet material crusher adopts a high alloy wear-resistant hammer, and the hammer is made of forging. It is particularly strong and wear-resistant, which is stronger and more wear-resistant than the ordinary hammer, and increases the service life of the hammer.
  • 04. Semi-wet material crusher adopts two-way clearance technology, if the hammer is worn, it does not need to be repaired, and the position of the hammer can continue to be used. Adjusting the gap between the hammer head and the liner can control the material size of the material.
  • 05. Semi-wet material crusher only needs one person to be easy to operate, not only safe and reliable but also easy to maintain.
  • 06. Semi-wet material crusher centralized lubrication system oil, normal work, without stopping can be injected lubricating oil.

Technical parameters

Specifications Power (kw) Capacity (t/h) Outline dimension (length*width*height)
LP500 7.5 1-3 670*590*1150
LP600 11 2-4 1100*750*1730
LP800 18.5 5-8 1300*900*2080
LP1000 37 8-12 1400*1150*2390
